StarTech - Startech Conference Room Docking Station with Power and Charging; Table Connectivity Box, Universal USB-C Laptop Dock, 60W PD, 4K HDMI, USB Hub, Audio, 2x AC Outlets, 2x USB BC 1.2 Charge Ports
Docking station - USB-C - HDMI - 1GbE - TAA Compliant
Product Description
What's Included
| Main Specifications | |
|---|---|
| Product Description | Startech Conference Room Docking Station with Power and Charging; Table Connectivity Box, Universal USB-C Laptop Dock, 60W PD, 4K HDMI, USB Hub, Audio, 2x AC Outlets, 2x USB BC 1.2 Charge Ports - docking station - USB-C - HDMI - 1GbE - TAA Compliant |
| Product Type | Docking station |
| Docking Interface | USB-C |
| Video Interfaces | HDMI |
| Dimensions (WxDxH) | 11 cm x 16.5 cm x 31.8 cm |
| Weight | 2.7 kg |
| Color | Black |
| Audio Output | - 7.1 channel surround |
| Networking | Gigabit Ethernet |
| Power | Power adapter AC 100-240 V (50/60 Hz) |
| TAA Compliant | Yes |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Product Type | Docking station |
| Width | 11 cm |
| Depth | 16.5 cm |
| Height | 31.8 cm |
| Weight | 2.7 kg |
| Enclosure Color | Black |
| Expansion / Connectivity | |
| Interfaces | 3 x display / video - HDMI - 19 pin HDMI Type A ¦ 1 x SuperSpeed USB 3.0 with Fast Charging - 9 pin USB Type A ¦ 3 x SuperSpeed USB 3.0 - 9 pin USB Type A ¦ 1 x network - RJ-45 ¦ 1 x SuperSpeed USB 3.0 - 24 pin USB-C ¦ 1 x SuperSpeed USB 3.0 - 9 pin USB Type B ¦ 1 x microphone - mini-phone 3.5 mm ¦ 1 x speakers - mini-phone 3.5 mm ¦ 2 x USB 2.0 - 4 pin USB Type A ¦ 2 x power - power IEC 60320 C13 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Cables Included | 1 x USB-C cable ¦ 1 x USB-A to USB-B cable ¦ 3 x power cable |
| Included Accessories | 4 x M4 screws, 8 x #6-32 x 3/8" screws, 16 x #6-32 x 3/16" screws, 8 x M5 screws, 2 x wing fasteners, 2 x cable management top plates, 2 x mounting brackets, lacing bar, large cable bushing, small cable bushing, cable management bracket |
| Features | Full duplex support, 4K Ultra HD, auto MDIX support, 60W power delivery |
| Compliant Standards | UL, FCC, RoHS, WEEE, cETLus, USB Battery Charging Specification Rev. 1.2, USB Power Delivery 2.0, UASP (USB Attached SCSI Protocol), UL 62368-1 |
| TAA Compliant | Yes |
| Networking | |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, USB 1.1, USB 2.0, USB 3.0, Power Delivery 2.0 |
| Power | |
| Power Device | Power adapter |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Video | |
| Max Resolution Details | 3840 x 2160 - 30 Hz |
| Audio | |
| Sound Output Mode | 7.1 channel surround |
| System Requirements | |
| OS Required | Microsoft Windows 7 / 8 / 8.1 / 10, Apple MacOS X 10.9 - 10.12, Google Chrome OS 55 or later, Apple macOS 10.14, Apple iPadOS, Apple macOS 10.15, Apple macOS Big Sur 11.0, Linux Kernel 4.15 or later |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 36 cm |
| Shipping Depth | 14 cm |
| Shipping Height | 24 cm |
| Shipping Weight | 5.7 kg |
