Elo Touch Solutions - EloPOS System i2
All-in-one - 1 x Celeron J4105 / 1.5 GHz - RAM 4 GB - SSD 128 GB - UHD Graphics 600 - GigE - WLAN: 802.11a/b/g/n/ac, Bluetooth 5.0 - no OS - monitor: LED 15.6" 1366 x 768 (HD) touchscreen - black
Elo Touch Solutions
E440439
0843173105161
N/A
New
Product Description
Additional Details
What's Included
Main Specifications | |
---|---|
Product Description | EloPOS System i2 - all-in-one - Celeron J4105 1.5 GHz - 4 GB - SSD 128 GB - LED 15.6" |
Type | Point of sale terminal - all-in-one |
Processor | 1 x Intel Celeron J4105 / 1.5 GHz (2.5 GHz) (Quad-Core) |
Cache Memory | 4 MB |
Cache Per Processor | 4 MB |
RAM | 4 GB (installed) / 8 GB (max) - DDR4 SDRAM - non-ECC |
Storage Controller | SATA (SATA 6Gb/s) |
Hard Drive | SSD 128 GB - SATA 6Gb/s - 2.5" |
Optical Storage | No optical drive |
Monitor | 15.6" - LED - 1366 x 768 (HD) - 16:9 - touchscreen |
Graphics Controller | Intel UHD Graphics 600 |
Audio Output | Stereo |
Networking | GigE, 802.11a, 802.11b/g/n, Wi-Fi 5, Bluetooth 5.0 |
Power | AC 120/230 V (50/60 Hz) |
OS Provided | No operating system |
Color | Black |
Dimensions (WxDxH) | 38.62 cm x 22.12 cm x 36.93 cm |
Weight | 4.9 kg |
Manufacturer Warranty | Limited warranty - 3 years |
General | |
Type | Point of sale terminal |
Product Form Factor | All-in-one |
Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
Color | Black |
Expansion / Connectivity | |
Bays | 1 (total) / 0 (free) x internal 2.5" x 1/8H |
Interfaces | 3 x USB 3.0 ¦ 2 x USB 2.0 ¦ 4 x USB 2.0 - micro-USB ¦ 2 x PoweredUSB (12 V) ¦ 1 x PoweredUSB (24 V) ¦ 1 x LAN (Gigabit Ethernet) - RJ-45 ¦ 1 x cash drawer ¦ 1 x headphones ¦ 2 x serial - RJ-45 ¦ 1 x USB-C (27 Watt charging) |
Manufacturer Warranty | |
Service & Support | Limited warranty - 3 years |
Miscellaneous | |
Cables Included | RJ-45 to DB-9 cable ¦ Power cable (2 pcs.) |
VESA Mounting Interface | 75 mm |
Compliant Standards | UL, TUV, VCCI, cUL, NOM, CB, CCC, FCC, S Mark, RCM, CE/EMC |
RAM | |
Installed Size | 4 GB / 8 GB (max) |
Technology | DDR4 SDRAM - non-ECC |
Effective Memory Speed | 2400 MHz |
Rated Memory Speed | 2666 MHz |
Form Factor | SO-DIMM 260-pin |
Slots | 2 (total) / 1 (empty) |
Features | Unbuffered |
Configuration Features | 1 x 4 GB |
Networking | |
Wireless LAN Supported | Yes |
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.0 |
Power | |
Device Type | Power adapter |
Installed Qty | 1 |
Voltage Required | AC 120/230 V (50/60 Hz) |
Power Provided | 180 Watt |
Power Consumption Operational | 24 Watt |
Environmental Parameters | |
Min Operating Temperature | 0 °C |
Max Operating Temperature | 35 °C |
Humidity Range Operating | 20 - 80% (non-condensing) |
Storage Controller | |
Type | 1 x SATA |
Controller Interface Type | SATA 6Gb/s |
Cache Memory | |
Installed Size | 4 MB |
Cache Per Processor | 4 MB |
Optical Storage | |
Type | No optical drive |
Operating System / Software | |
OS Provided | No operating system |
Monitor | |
Monitor Type | LED |
Touchscreen | Yes (10-point multi-touch) |
Diagonal Size | 15.6" |
Native Resolution | 1366 x 768 (HD) |
Widescreen Display | Yes |
Image Aspect Ratio | 16:9 |
Horizontal Viewing Angle | 90 |
Vertical Viewing Angle | 50 |
Response Time | 10 ms |
Image Brightness | 220 cd/m² |
Image Contrast Ratio | 400:1 |
Monitor Features | Anti-glare, TouchPro technology |
Graphics Controller | |
Graphics Processor | Intel UHD Graphics 600 |
Audio Output | |
Sound Output Mode | Stereo |
Speakers Included | 2 x right / left channel |
Hard Drive | |
Type | SSD - 2.5" |
Capacity | 1 x 128 GB |
Interface Type | SATA 6Gb/s |
SSD Endurance | 72 TB |
Dimensions & Weight | |
Dimensions & Weight Details | 38.62 cm - 22.12 cm - 36.93 cm - 4.9 kg - with stand ¦ 38.62 cm - 7.33 cm - 24.89 cm - 2.9 kg - without stand |
Width | 38.62 cm |
Depth | 22.12 cm |
Height | 36.93 cm |
Weight | 4.9 kg |
Dimensions & Weight (Shipping) | |
Shipping Width | 46.2 cm |
Shipping Depth | 29.9 cm |
Shipping Height | 47 cm |
Shipping Weight | 7.3 kg |
Processor / Chipset | |
CPU | Intel Celeron J4105 |
Clock Speed | 1.5 GHz |
Max Turbo Speed | 2.5 GHz |
Number of Cores | Quad-Core |
CPU Qty | 1 |
Max CPU Qty | 1 |
